Arrow Lake / Panther Lake AMI unverified 32 MB
INTEL
iGame Z890 VULCAN X V20
Settings
8.169
Hidden
7.498
Visible
671
Forms
380
VarStores
124
Strings
17.281
Probes
6
PFAT
0
BIOS-Engine & OEM-Erweiterungen
hohe Sicherheit
AMI Aptio V
AMI Aptio V Setup-Engine
Evidenz 1
AMI Setup Engine module name
6×
// CPU & Microcode
INTEL
Prozessor-Initialisierung
CSME / ME
19.0.5.2175
Platform
Arrow Lake / Panther Lake
µCode Revision
0x00000018
µCode CPUID
0x000C0660
µCode Datum
2024-05-16
Board-Vendor
Colorful
BIOS-Vendor
AMI
▶
// CPU Support List
3 Microcodes
3/3 bekannt
▶ CPUID 0x000C0660 µCode-Rev 0x00000018 Datum 2024-05-16 18 CPUs
Core Ultra 9 285K
Ultra 9
Cores / Threads
8P+16E / 24T
Base Clock
3.7 GHz
Cache
36 MB
TDP
125 W
Core Ultra 9 285
Ultra 9
Cores / Threads
8P+16E / 24T
Base Clock
2.5 GHz
Cache
36 MB
TDP
65 W
Core Ultra 9 285T
Ultra 9
Cores / Threads
8P+16E / 24T
Base Clock
1.4 GHz
Cache
36 MB
TDP
35 W
Core Ultra 7 265K
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
3.9 GHz
Cache
30 MB
TDP
125 W
Core Ultra 7 265KF
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
3.9 GHz
Cache
30 MB
TDP
125 W
Core Ultra 7 265
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
2.4 GHz
Cache
30 MB
TDP
65 W
Core Ultra 7 265F
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
2.4 GHz
Cache
30 MB
TDP
65 W
Core Ultra 7 265T
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
1.5 GHz
Cache
30 MB
TDP
35 W
Core Ultra 5 245K
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
4.2 GHz
Cache
24 MB
TDP
125 W
Core Ultra 5 245KF
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
4.2 GHz
Cache
24 MB
TDP
125 W
Core Ultra 5 245
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
3.5 GHz
Cache
24 MB
TDP
65 W
Core Ultra 5 245T
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
2.2 GHz
Cache
24 MB
TDP
35 W
Core Ultra 5 235T
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
2.2 GHz
Cache
24 MB
TDP
35 W
Core Ultra 5 235
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
3.4 GHz
Cache
24 MB
TDP
65 W
Core Ultra 5 230F
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
3.4 GHz
Cache
24 MB
TDP
64 W
Core Ultra 5 225F
Ultra 5
Cores / Threads
6P+4E / 10T
Base Clock
3.3 GHz
Cache
20 MB
TDP
65 W
Core Ultra 5 225
Ultra 5
Cores / Threads
6P+4E / 10T
Base Clock
3.3 GHz
Cache
20 MB
TDP
65 W
Core Ultra 5 225T
Ultra 5
Cores / Threads
6P+4E / 10T
Base Clock
2.5 GHz
Cache
20 MB
TDP
35 W
▶ CPUID 0x000C0662 µCode-Rev 0x00000121 Datum 2025-12-15 3 CPUs
Refresh-Launch mit hoeheren Boost-Clocks. Gleicher Die, neue BIOS-Microcode-Unterstuetzung.
Core Ultra 7 270K PLUS
Ultra 7
Cores / Threads
8P+12E / 20T
Base Clock
3.7 GHz
Cache
36 MB
TDP
125 W
Core Ultra 5 250K PLUS
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
4.2 GHz
Cache
30 MB
TDP
125 W
Core Ultra 5 250KF PLUS
Ultra 5
Cores / Threads
6P+8E / 14T
Base Clock
4.2 GHz
Cache
30 MB
TDP
125 W
▶ CPUID 0x000A06C1 µCode-Rev 0x00000005 Datum 2023-12-01 Pre-Release
Meteor Lake-S wurde als Desktop-Produkt 2023 gecancelt — die 'Core Ultra 1xx'-Desktop-Serie wurde zugunsten von Arrow Lake-S aufgegeben. Microcode-CPUID 0x000A06C1 bleibt in Boards als Engineering-Fallback / Compatibility-Entry. Mobile MTL-U/H (0x000A06A4) haben separate CPUIDs.
Noch keine Consumer-CPUs released.
// Memory Features
Status
Teilweise
XMP 3.0 nur teilweise integriert: DDR5-Plattform plus 1 3.0-Signal(e), aber UI-Integration nicht vollstaendig (>=3 Signale erwartet fuer voll). Verfuegbar: Profile 3.
› Evidence-Details (3 Signale · Confidence 85%)
Tier 1
platform
(filename) 5958bfacedc91c565b8d9c1d4c837398b8a1f3049fd274e1f0c9420c8f3cd4a4_iGame_Z890_VULCAN_X_V20_1023
LGA1851 (Arrow Lake-Era, XMP 3.0 standard) — aus Filename
Tier 2
xmp_base_signals
XMP Profile
8x
XMP-UI-Strings gefunden: XMP Profile
Tier 2
xmp_30_signals
Profile 3
7x
XMP-3.0-spezifische Strings: Profile 3
// KI-Analyse
Colorful Z890 VULCAN X mit Intel Arrow Lake/Panther Lake Platform und AMI UEFI. Auffällig sind versteckte Power Limit 4 Optionen, SOC-North Efficient-Core Settings und experimentelle VTIO SDEV Exposure Controls für verschiedene Intel-Subsysteme.
Befunde 5
notable
SOC-North Efficient-Cores Konfiguration
Neue Hardware
Das BIOS enthält eine separate Konfigurationsoption für 'Active SOC-North Efficient-cores', was auf eine neue CPU-Architektur mit mehreren E-Core-Clustern hindeutet. Dies ist ein Indikator für erweiterte Heterogeneous Computing Features in Arrow Lake/Panther Lake.
Active SOC-North Efficient-cores: All [VERSTECKT] (CpuSetup:0x356)
interesting
Power Limit 4 Implementation
Neue Hardware
Intel hat ein viertes Power Limit eingeführt (PL4) mit separaten Override-, Lock- und Boost-Controls. Dies erweitert das bekannte PL1/PL2-System erheblich und deutet auf komplexere Thermal-Management-Strategien hin.
Power Limit 4 Override: Disabled (CpuSetup:0x25), Power Limit 4: 0 [VERSTECKT] (CpuSetup:0x26), Power Limit 4 Lock: Disabled [VERSTECKT] (CpuSetup:0x2A), Power Limit 4 Boost: 0 (CpuSetup:0x2B)
interesting
VTIO SDEV Exposure Controls
Verstecktes Feature
Das BIOS bietet granulare Kontrolle über VTIO SDEV (Secure Device) Entries für verschiedene Intel-Subsysteme wie CIO2, ISP, HECI und SPI-Controller. Diese sind normalerweise hardcoded und deuten auf erweiterte Virtualization/Security Features hin.
Expose CIO2 SDEV Entry: Disabled [VERSTECKT] (VtioCfg:0x2), Expose ISP SDEV Entry: Disabled [VERSTECKT] (VtioCfg:0x3), Expose HECI SDEV Entry: Disabled [VERSTECKT] (VtioCfg:0x4)
interesting
Experimenteller Microcode
Experimentell
Der Microcode 0x18 für CPUID 0xC0660 ist ungewöhnlich niedrig für eine Production-CPU. Arrow Lake würde normalerweise höhere Microcode-Revisionen haben, was auf Pre-Production oder Engineering-Samples hindeutet.
Microcode: 0x00000018 (CPUID: 0x000C0660)
info
Intel ME 19.0 Generation
Neue Hardware
Management Engine Version 19.0.5.2175 entspricht der neuesten ME-Generation für Arrow Lake/Panther Lake Platform. Die hohe Build-Nummer deutet auf eine späte Entwicklungsphase hin.
ME Version: 19.0.5.2175
